CE/ISO 9001 Certified Sandwich Panel FFU Fan Filter Unit for
Turnkey Cleanroom Project
Modular Cleanroom is a pre-engineered, self-contained clean
environment that is designed to meet specific cleanliness and
contamination control requirements.
| Configuration: |
| Cleanroom Project Scope(from structure, HVAC,electric to autoc
ontrol) | 1. Cleanroom Structure: Wall Panel, Ceiling Panel, Windows, Doors,
Fttings, Flooring |
| 2. HVAC: AHU, Chiller, dehumidifier, Ducting, Piping, etc. |
| 3. Electric: Lighting, Switch, Cables, Wires, Power Distribution
Cabinet, etc |
| 4. Auto- control: PLC Controller, Sensors for Humidity and
Temperature, Control Panel |
| 5. Process Piping System: Gas, Water Pipeline |
| Equipment | Air shower, Cargo shower, Mist shower, Dynamic pass box, Static
pass box, Sampling booth,Weighing booth, Dispensing booth, |
| Medicine stability test chamber, isolator, VHP
sterilizer,Biological safety chamber, FFU, LAF, etc. |
| Temperature | 21-27*C (or as per required) |
| Humidity | 30-60C (or as per required) |
| Application | Pharmaceutical factory, hospital, medical device factory,
electronics factory, food factory, cosmetics factory, etc. |
| Qualification Documents | CE GMP ISO |
| Full Service | FAT and SAT Service, Professional Consultation, Training, 24 hours
technical support |
Structure:
Frame: The frame of a modular cleanroom is typically constructed using
high-quality materials such as stainless steel or aluminum alloy.
Stainless steel offers corrosion resistance and high strength,
while aluminum alloy is known for its ease of installation and an
attractive appearance.
Ceiling: The ceiling is often made of lightweight materials like aluminum
plastic panels, which are convenient to install.
Walls: The wall materials can vary. Transparent acrylic panels are strong
and relatively inexpensive. Anti-static acrylic panels have a
surface with anti-static properties, making them suitable for
cleanrooms where an electrostatic-free environment is required for
the process. Color steel plates are used for their dust-proof and
durable characteristics.
Fan Filter Units (FFU): FFUs are a crucial component of the modular cleanroom. They use
high-quality, energy-efficient, and low-noise fans, or
customer-specified brands like German EBM. The outer casing of the
FFU is usually made of galvanized aluminum or stainless steel.
Control System: The control system, often developed by the manufacturer, is
responsible for uniformly controlling the FFU to regulate air
speed, pressure difference, and temperature and humidity (if an air
conditioning system is配套). This helps maintain a stable and
controlled cleanroom environment.
Doors and Windows: Cleanroom doors and windows are designed to seal tightly to
prevent the ingress of contaminants. They may also have specific
features such as smooth surfaces and easy operation.
Filters: High-efficiency or ultra-high-efficiency filters are installed to
remove particles and contaminants from the air, ensuring a high
level of cleanliness within the cleanroom.
Utilities and Services: Provisions for electrical wiring, lighting, and other necessary
utilities are integrated into the structure. Additionally, there
may be options for installing monitoring systems to keep track of
environmental parameters.
The modular design of these cleanrooms offers several advantages.
They can be easily assembled, disassembled, and relocated,
providing flexibility in facility layout changes. Compared to
traditional cleanroom construction, they can be produced and set up
in a shorter time and at a lower cost. Moreover, they are
free-standing structures and do not necessarily require attachment
to the roof. The ability to customize the size, layout, and
cleanroom class according to specific needs makes them suitable for
a wide range of applications in industries such as electronics,
semiconductors, biopharmaceuticals, food, and more.
