Brand Name : | OEM |
Supply Ability : | 1000 Set/Sets per Month |
Price : | $100.00 - $180.00/sets |
Item | Technical Parameter Description | ||||||
Door Frame Shape | Flat frame type, encircle frame type, clamping type, plug-in type
(customized according to customer requirements) | ||||||
Material | Electrogalvanized steel plate, 1.5mm for door frame, 1.0mm for door
panel,1.2mm for inner reinforcing plate | ||||||
Filler | Flame retardant paper honeycomb | Fireproof aluminum honeycomb | Rock wool | Polyurethane foam | |||
Door Leaf Window | Square Glass | Oval glass | Square outside and round inside glass | Single, double galss | |||
Hardware Accessories | Locks: separate execution lock, compact execution lock, elbow press
lock, escape lock, touch bead lock, etc. | ||||||
Hinge: detachable type, semi-hidden adjustment type, spring
hydraulic type, hidden type, etc. | |||||||
Sealing device: door leaf self-adhesive type, door frame embedded
type, door bottom automatic lifting type. | |||||||
Surface Treatment | Spraying (outdoor fluorocarbon powder, electrostatic powder),
stoving varnish, paint-free (color can be customized according to the customer requirements) | ||||||
Wind Resistance Performance P3(KPa) | 2.8 Air Pressure 100.8KPa | Airtightness q1=1.0 -q1=0.6 | |||||
q(m³/(m-h)) q2=2.1 -q1=1.5 | |||||||
Door Leaf Weight m²/KG | Paper honeycomb | Aluminum honeycomb | Rock wool | Polyurethane | |||
21.5KG | 22.3KG | 24.5KG | 26.0KG |
Features:
1. High sealing performance: To ensure the cleanliness and
stability of the internal environment of the cleanroom.
2. Smooth surface: Facilitates easy cleaning and reduces the
accumulation of dirt and bacteria.
3. Anti-static material: Prevents the generation and accumulation
of static electricity, reducing the impact on sensitive electronic
components.
4. Durable construction: Made of high-quality materials to
withstand frequent use and harsh conditions.
Applications:
1. Pharmaceutical industry: Maintaining a sterile environment for
drug production.
2. Electronics manufacturing: Protecting sensitive electronic
components from contamination.
3. Hospitals and laboratories: Ensuring the safety and purity of
medical and research processes.
Advantages:
1. Improved product quality: Reduces the risk of contamination,
leading to higher-quality end products.
2. Energy efficiency: Helps maintain a stable temperature and
humidity, reducing energy consumption.
3. Enhanced safety: Prevents the entry of external pollutants and
protects workers' health.
4. Long service life: Low maintenance requirements and reliable
performance over time.
Packaging and Transportation:
1. The cleanroom doors are carefully wrapped with protective
materials to prevent scratches and damage during transportation.
2. They are placed in sturdy crates or container
![]() |
