Brand Name : | Tianjia |
Model Number : | Single person single blow |
Certification : | CE,ISO |
Price : | $3500.00/sets 1-4 sets $3000.00/sets 5 sets |
Payment Terms : | T/T, L/C |
Supply Ability : | 100 Set/Sets per Month |
HEPA Filter Included 304 Stainless Steel Cleanroom Air Shower
Product Features:
1. Humanized control panel design, clear indicator light
indication, and clear air shower flow indication. Soft key touch
type time relay;
2. High cleanliness and wind speed: two-stage filtration system
with primary and high efficiency filters is adopted, no partition
plate with low resistance and high efficiency filters. The
filtration efficiency is 99.99% to ensure the clean level. Equipped
with all stainless steel multi-angle adjustable nozzle, double
volute outer rotor large air volume and low noise fan, the air
outlet wind speed of the air nozzle is as high as more than 25 m/s,
and the wind speed is more than 18 m/s when blowing on people.
3. Modular structure. The air shower box adopts a modular design
scheme, which can be assembled into various lengths of air shower
sizes according to actual demand. One air shower is composed of one
or multiple air shower units. For large-volume air shower
equipment, it can be divided into multiple modules which making
production, transportation and installation particularly convenient
and fast;
4. High performance and high sealing: Qualified electronic
components, stable and reliable operation performance, advanced
noise reduction and mute device system with EVA high sealing
material.
Applications:
1. Automatic control. The single-person single-blowing air shower
system adopts PLC intelligent control means. The LED display screen
on the control panel can correctly display the running state of air
shower, the interlocking state of double doors, the progress of air
shower cycle and the delayed opening state. It is also equipped
with a photoelectric sensor and a one-way channel air shower room,
which enters from the non-clean area. After closing the door, the
infrared ray senses the person to blow the shower. After blowing
the shower, the entrance is locked and the air shower room can only
be walked out of the air shower room from the door;
2. Single-person single-blown air shower main board soft key touch
time relay, LED display and set blowing time, adjustable in the
range of 10-99s, which can adjust the blowing time according to the
difference of the external environment of the air shower room;
3. Modular structure, single-person single-blowing shower chamber
box adopts modular design solution.
Advantages:
1. Improved Cleanliness: By removing contaminants from personnel
and objects, it significantly reduces the risk of contamination in
the cleanroom, improving the overall cleanliness level.
2. Enhanced Product Quality: Helps to ensure the quality and
reliability of products manufactured in cleanroom environments,
especially in industries where precision and purity are crucial.
3. Cost-Effective: Compared to other contamination control
measures, air showers offer a cost-effective solution for
maintaining cleanroom standards.
4. Increased Efficiency: The quick and efficient decontamination
process enables smooth workflow and reduces downtime.
5. Compliance with Standards: Helps facilities comply with strict
industry standards and regulations regarding cleanliness and
contamination control.
Packaging and Transportation:
Specification:
Exterior Size | W1400*D1000*H2250 | W1400*D1500*H2250 | W1400*D2000*H2250 |
InternalSize | W900*D900*H2100 | W900*D1400*H2150 | W900*D1900*H2150 |
Filter Efficiency | ≥99.99%(@≥0.3μm) | ||
Air Velocity | ≥20 m/s(4920fpm) | ||
Showering Time | 0~99 s (Adjustable) | ||
Num.of Nozzle | 12 | 18 | 24 |
Power Supply | AC380V, 3Φ, 50Hz | ||
Body | High grade steel with ivory color static powder coating | ||
Floor | Stainless steel bottom plate | ||
Door | Aluminum alloy with tempered glass |
![]() |
